Product information and support
Features and Benefits:
- Effective visual alarm: Single flash at 1 Hz (60 FPM) ensures a clear warning.
- Three light outputs: Choose 3, 10, or 15 J depending on visibility and distance.
- Five lens colors: Red, white, blue, green, or yellow for clear alarm differentiation.
- Anti-tamper option: Extra security where unintended access must be prevented.
Specifications:
- Operating voltage: 12/24 V DC
- Current consumption: 40 / 88 / 240 mA (3 / 10 / 15 cd)
- Light output: 3 / 10 / 15 J — min. 15 J for outdoor use
- Flash rate: 1 Hz (60 FPM)
- Temperature range: −25 °C to +70 °C
- Enclosure: IP66 (supplied base)
- Materials: Flame-retardant ABS base, polycarbonate lens
- Weight: 0.1 kg
- Dimensions: Ø 93 mm, height 63 mm (shallow)
With a single unit you can cover everything from standard process monitoring to fire alarms. The pre-mounted 12/24 V base with IP66 sealing makes installation plug-and-play and provides maximum protection against water and dust. The three brightness levels make it easy to manage power consumption and avoid glare in small rooms. Multiple lens colors let you tailor the signal to your alarms or apply color-coding so personnel quickly understand the risk. In short: you get a simple, robust solution that can grow with your needs while minimizing installation and operating costs.
A clear visual alarm reduces reaction time, especially where hearing protection or machine noise can drown out sirens. The beacon synchronizes automatically so multiple units flash simultaneously — improving visibility in large halls and outdoor areas. At the same time, the low power consumption means it can run from existing power supplies, and the IP66 protection means the beacon withstands heavy washdown and outdoor use without additional enclosures.
The result is fewer false alarms, higher uptime, and a clear visual safety line for your personnel.
A reliable gas detection system starts with a thorough assessment of your workplace environment. With years of experience identifying risk areas and designing tailored solutions, we can help determine whether this product is the right fit for your needs.
Whether you need this product as a standalone solution or as part of a larger system, we’ll make sure it’s aligned with your workplace’s specific requirements. We work closely with you to ensure the solution meets both safety standards and the unique challenges of your operations.
Learn more about how we can help you find the right solution here.
