Features and Benefits:
- Effective visual alarm: Single flash at 1 Hz (60 FPM) for clear warning.
- Three light outputs: Select 3 / 10 / 15 cd depending on distance and visibility requirements.
- Five lens colours: Red, white, blue, green or amber for clear differentiation.
- Anti-tamper option: Additional protection where unauthorized access must be prevented.
- Direct 230 V AC connection: Connects directly without an additional power supply.
Specifications:
- Operating voltage: 230 V AC
- Light output: 3 / 10 / 15 cd
- Flash rate: 1 Hz (60 FPM)
- Temperature range: –25 °C to +70 °C
- Enclosure: IP66 (with supplied base)
- Material: Flame-retardant ABS base, polycarbonate lens
- Weight: 0.1 kg
- Dimensions: Ø 93 mm, height 100 mm
Direct 230 V connection simplifies installation and reduces the number of components in the control panel. The IP66 protection rating ensures reliable operation in wash-down environments and outdoor installations. With three selectable light levels, you can balance visibility and energy consumption, while colour-coded lenses make it easy for personnel to identify the alarm type at a glance. The result is faster response, improved uptime, and a consistent visual safety signal throughout the facility.
A reliable gas detection system starts with a thorough assessment of your workplace environment. With years of experience identifying risk areas and designing tailored solutions, we can help determine whether this product is the right fit for your needs.
Whether you need this product as a standalone solution or as part of a larger system, we’ll make sure it’s aligned with your workplace’s specific requirements. We work closely with you to ensure the solution meets both safety standards and the unique challenges of your operations.
Learn more about how we can help you find the right solution here.
