Product information and support
Features and Benefits:
- Powerful alarm: 106 dB(A) at typical tone 3 ensures clear warning in noisy environments.
- 32 user-selectable tones: from classic siren to pulsed signals — easy to align with procedures.
- Two-stage alarm: switch between pre-alarm and main alarm via a single control line.
- Automatic synchronization: multiple sounders start in step so the signal doesn’t “muddy.”
Specifications:
- Operating voltage: 12 / 24 V DC (via IP66 base)
- Current consumption: ~40 mA (typical)
- Sound pressure level: 106 dB(A) @ 1 m (typ. tone 3)
- Tones: 32 selectable + two-stage alarm
- Volume control: 10 dB adjustable
- Temperature range: −25 °C to +70 °C
- Enclosure: IP66 (base) — ABS housing
- Weight: 0.25 kg
- Dimensions: Ø 93 mm, height 63 mm
With a single sounder you can cover everything from process monitoring to evacuation alarms in areas with high background noise. The factory-fitted IP66 base provides maximum sealing and simplifies installation: one unit, one hole, done. Low power consumption (approx. 40 mA) makes it possible to reuse existing supplies, and the 32 tones give you the freedom to implement clear, unambiguous warnings without confusing staff across departments.
The sounder inspires confidence because the high output and wide tone selection ensure personnel immediately detect a critical situation — even when wearing hearing protection or working in noisy zones. The factory-mounted IP66 base makes installation simple and robust: one unit, one entry, and you achieve full protection against water, dust, and impact without investing in additional enclosures. At the same time, the low power draw keeps operating costs down and enables reuse of existing power supplies. Finally, the 32 tones and two-stage alarm mean the system can be adjusted as safety procedures and regulations change, delivering a solution that boosts safety today and preserves its value over the long term.
A reliable gas detection system starts with a thorough assessment of your workplace environment. With years of experience identifying risk areas and designing tailored solutions, we can help determine whether this product is the right fit for your needs.
Whether you need this product as a standalone solution or as part of a larger system, we’ll make sure it’s aligned with your workplace’s specific requirements. We work closely with you to ensure the solution meets both safety standards and the unique challenges of your operations.
Learn more about how we can help you find the right solution here.
