Features and Benefits:
- Powerful alarm: 106 dB(A) at typical tone 3 ensures clear warning even in noisy environments.
- 32 user-selectable tones: From classic siren signals to pulsed alert tones.
- Two-stage alarm: Switch between pre-alarm and main alarm via a single control wire.
- Automatic synchronization: Multiple horns start in sync, preventing signal overlap or distortion.
- 230 V AC – direct connection: Easy integration into existing 230 V circuits.
- IP66 base: Protected against dust and powerful water jets – suitable for harsh environments.
Specifications:
- Operating voltage: 230 V AC (via IP66 base).
- Power consumption: Not specified for the 230 V AC base.
- Sound pressure level: 106 dB(A) @ 1 m (typ. tone 3).
- Tones: 32 selectable tones + two-stage alarm.
- Volume control: Adjustable by 10 dB.
- Temperature range: –25 °C – +70 °C.
- Enclosure: IP66 (base) – ABS housing.
- Weight: 0.25 kg.
- Dimensions: Ø 93 mm, height 100 mm.
With direct 230 V connection, the horn can be connected to existing mains circuits without the need for an additional power supply, simplifying installation and servicing. The IP66 rating ensures reliable operation in environments with dust and wash-down conditions, while the combination of 106 dB(A), 32 tones, and two-stage alarm makes it easy to create a clear and standardized acoustic warning, even in noisy environments.
A reliable gas detection system starts with a thorough assessment of your workplace environment. With years of experience identifying risk areas and designing tailored solutions, we can help determine whether this product is the right fit for your needs.
Whether you need this product as a standalone solution or as part of a larger system, we’ll make sure it’s aligned with your workplace’s specific requirements. We work closely with you to ensure the solution meets both safety standards and the unique challenges of your operations.
